Roll-Around Wide Span Unit

• Unit has four swivel casters and comes equipped with locking mechanism to securely hold the unit in place
• 42"W (1067 mm) optional sign holder will hold a 41"W (1041 mm) x 15"H (381 mm) x 1/8"D (8 mm) sign
• 48" (1219 mm) optional sign holder will hold a 47"W (1193 mm) x 15"H (381 mm) x 1/8"D (8 mm) sign
• Weight capacity 2800 lbs
• Standard finishes: Sahara or Blue Gray

Roll-Around Wide Span Unit
Part Description		QTY
A	Regular-Duty Wide Span Frame	As Required
B*	Regular-Duty Wide Span Deck Support	2
C	Regular-Duty Wide Span Beams	As Required
D	5/8" Particle Board Decks	As Required
E	4" Swivel Caster	4
F	Locking Mechanism	2

*Regular-Duty Wide Span Deck Support is not visible
