Bulk Merchandiser

Bulk Merchandiser

Contact Us Today

  • Bulk Merchandiser

    Top platform allows display of large profile merchandise requiring a strong support system. Boxed merchandise can be stacked on base beneath corresponding displayed product. Multiple configurations available.

      When "HM" beams are ordered with Bulk Merchandiser, uprights are on 48" centerlines and overall length of unit is total of beam lengths plus 1 3/4"
    • Bulk Merchandiser
      Part Description Part Number QTY
      A Wide Span Frame Extension WSFE-4860 as required
      B Wide Span Frame Connector WSSFC-2 1 pair per frame
      C Wide Span Single Deck Display Frame WSSDDF-(ND)(NH) as required
      D Heavy-Duty Front Beam Upper HMHDFB48-U as required
      E* Wide Span Heavy-Duty Deck Supports HDWSDS48 as required
      F Wide Span Single Display Deck Frame, Sealed WSSDDFD4848-S as required

      *Not shown here

    • Components for Bulk Merchandiser

      Reveal/Hide Components

       Heavy-Duty Front Beam Upper

      • Heavy gauge beam body with integral connectors fits snugly into Upright slots and maintains deck alignment with basic fixture slotting
      • One beam pair is required per deck
      • Standard finishes: Sahara or Blue Gray
      Part Number: HMHDFB48-U
      • HMHD..... Heavy-Duty
      • FB..... Front Beam
      • 48.....Nominal Width 48" (1219 mm)
      • U.....Upper
      HMHDFB48-U-Heavy-Duty Front Beam Upper

       Heavy-Duty Wide Span Deck Supports

      • Formed steel component easily rotates into place, ties beams together and supports deck
      • Standard finishes: Sahara or Blue Gray
      Part Number: HDWSDS48
      • HDWSDS... Heavy-Duty Wide Span Deck Supports
      • 48.....Nominal Width 48" (1219 mm)
      HDWSDS48-Heavy-Duty Wide Span Deck Supports

       Wide Span Frame Connector

      • Heavy gauge channel with hardware for connecting any two frames listed to obtain overall heights from 168" to 240" (4267 mm to 6096 mm)
      • Packages of two only
      • One set per Wide Span Frame Extension
      • Standard finishes: Sahara or Blue Gray
      Part Number: WSFC-2
      • WSFC..... Wide Span Frame Connector
      • 2..... Pair of 2
      WSFC-2-Wide Span Frame Connector

       Wide Span Frame Extension

      • Used for two level Bulk Merchandiser
      • Allows for reconfiguration in store
      • Standard finishes: Sahara or Blue Gray
      Part Number: WSFE-4860
      • WSFE..... Wide Span Frame Extension
      • NW.....Nominal Width 48" (1219 mm)
      • NH..... Nominal Height 60" (1524 mm)
      WSFE-4860-Wide Span Frame Extension

       Wide Span Single Deck Display Frame

      • Two required for Bulk Merchandiser Display starter
      • One additional for each added section
      • Standard finishes: Sahara or Blue Gray
      Part Number: WSSDDF-4806
      • WSSDDF....Wide Span Single Deck Display Frame
      • 48.....Nominal Depth 48" (1219 mm)
      • 06..... Nominal Height 6" (152 mm)
      WSSDDF-4806-Wide Span Single Deck Display Frame

       Wide Span Single Deck Display Frame, Sealed

      • Durable 5/8" particle board
      • Sealed deck with polymer wax finish
      Part Number: WSSDDFD-4848-S
      • WS.....Wide Span SDDFD..... Single Deck Display Frame
      • SDDFD..... Single Deck Display Frame
      • 48.....Nominal Length 48" (1219 mm)
      • 48.....Nominal Depth 48" (1219 mm)
      • S..... Sealed
      WSSDDFD-4848-S-Wide Span Single Deck Display Frame, Sealed
